Name: Drainage Servitudes

Display Field: NAMEGIVEN

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: This layer originated by Ascension Parish Drainage to document all easements obtained and recorded. It was further expanded to a contract with Elos Enivonmental whereas they did additional ROW verification for East Ascension Drainage. This dataset incroproates both efforts together into one drainage easement layer. This combine was accomplished in June of 2022 and is now the active dataset that both Elos and the Parish accesses to update as necessary. It is intended not for public sharing to ensure incorrection information is not provided. It does not reflect ALL easements, but ones identified and documented as part of this effort. This status of 6/21/22, whereas a secure published web service is created to allow continua updating. update: Append 534 easements from Elos on 08/01/2023, Data resource is ELOS, DrainageAreatype is Easement

Service Item Id: 9d01f8d8bba940ba994bedabc5998c5e

Copyright Text: Ascension Parish East Ascension Drainage & Elos

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 24000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 3352525.371029392
YMin: 572606.9628413767
XMax: 3454544.1374638975
YMax: 671799.9199668765
Spatial Reference: 102682  (3452)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: Servitude_Status
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: Granted
  Label: Granted
  Description: N/A
  Symbol:
  Style: esriSFSBackwardDiagonal
  Color: [152, 230, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [76, 230, 0, 154]
  Width: 2
• Value: CAUTION
  Label: CAUTION - Data requires verification
  Description: N/A
  Symbol:
  Style: esriSFSBackwardDiagonal
  Color: [255, 211, 127, 255]
  Outline:
  Style: esriSLSSolid
  Color: [255, 170, 0, 255]
  Width: 1
• Value: Proposed
  Label: Proposed
  Description: N/A
  Symbol:
  Style: esriSFSBackwardDiagonal
  Color: [255, 255, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [230, 230, 0, 255]
  Width: 1
• Value: Revoked
  Label: Revoked
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [168, 0, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [168, 0, 0, 255]
  Width: 0
• Value: Adopted Lateral
  Label: Adopted Lateral
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [0, 174, 239, 255]
  Outline:
  Style: esriSLSSolid
  Color: [0, 174, 239, 255]
  Width: 0
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: true

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• DATECREATED ( type: esriFieldTypeString, alias: DateCreated, length: 50 )
• ORDNO ( type: esriFieldTypeString, alias: OrdNo, length: 50 )
• NAMEGIVEN ( type: esriFieldTypeString, alias: NameGiven, length: 50 )
• NUMBERGIVEN ( type: esriFieldTypeString, alias: NumberGiven, length: 50 )
• WIDTH_FT ( type: esriFieldTypeString, alias: Width_ft, length: 50 )
• LENGTH_FT ( type: esriFieldTypeString, alias: Length_ft, length: 50 )
• RECORDEDNO ( type: esriFieldTypeString, alias: RecordedNo, length: 50 )
• CARTID ( type: esriFieldTypeString, alias: CartID, length: 50 )
• AREATYPE ( type: esriFieldTypeString, alias: AreaType, length: 50 , Coded Values: [Servitude: Servitude] , [Ditch: Ditch] , [Easement: Easement] , ...2 more... )
• Date_Executed ( type: esriFieldTypeDate, alias: Date Executed, length: 8 )
• Date_Recorded ( type: esriFieldTypeDate, alias: Date Recorded, length: 8 )
• Date_Expire ( type: esriFieldTypeDate, alias: Expiration Date, length: 8 )
• InstrumentNumber ( type: esriFieldTypeString, alias: Instrument Number, length: 255 )
• Parties_Names ( type: esriFieldTypeString, alias: Parties Names, length: 255 )
• LotNumber ( type: esriFieldTypeString, alias: Lot Number, length: 255 )
• WaterWay ( type: esriFieldTypeString, alias: Waterway Name, length: 255 )
• Road_Name ( type: esriFieldTypeString, alias: Road Name, length: 255 )
• DocType ( type: esriFieldTypeString, alias: Document Type, length: 255 , Coded Values: [Right-of-Way Acquisition: Right-of-Way Acquisition] , [Property Boundary Survey: Property Boundary Survey] , [Drainage Right-of-Way-Grant: Drainage Right-of-Way-Grant] , ...10 more... )
• Period ( type: esriFieldTypeString, alias: Period, length: 255 )
• Book ( type: esriFieldTypeString, alias: Book, length: 255 )
• Page ( type: esriFieldTypeString, alias: Page, length: 255 )
• ParcelNumber ( type: esriFieldTypeString, alias: Parcel Number, length: 255 )
• Resource ( type: esriFieldTypeString, alias: Data Source, length: 255 , Coded Values: [ELOS: ELOS] , [APG: APG] )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• APGID ( type: esriFieldTypeString, alias: APGID, length: 255 )
• DESCRIPTION ( type: esriFieldTypeString, alias: DESCRIPTION, length: 255 )
• Servitude_Status ( type: esriFieldTypeString, alias: Servitude Status, length: 255 , Coded Values: [Granted: Granted] , [Proposed: Proposed] , [Revoked: Revoked] , ...3 more... )
• Digitization_Method ( type: esriFieldTypeString, alias: Digitization_Method, length: 255 , Coded Values: [CAD File: CAD File] , [Georeference: Georeference] , [Ground Feature: Ground Feature] , ...1 more... )
• Notes ( type: esriFieldTypeString, alias: Notes, length: 255 )
• Confidence ( type: esriFieldTypeSmallInteger, alias: Confidence , Coded Values: [1: Low] , [2: Medium] , [3: High] )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• ROW_AGENT ( type: esriFieldTypeInteger, alias: ROW Agent Approval , Coded Values: [0: No] , [1: Yes] )
• Subdivision_Type ( type: esriFieldTypeString, alias: Subdivision Type, length: 255 , Coded Values: [Comm_Development: Commercial Development] , [Res_Sub: Residential Subdivision] , [Simple_Sub: Simple Subdivision] , ...1 more... )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• SHAPE.STArea() ( type: esriFieldTypeDouble, alias: SHAPE.STArea() )
• SHAPE.STLength() ( type: esriFieldTypeDouble, alias: SHAPE.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
